Quick Details

  • Products Status: Stock, Used
  • Type: Industrial Computer Accessories, Panel PC
  • Brand Name: TFTBAY
  • Model Number: TB-IPPC-AJ-104-D525B-PCI-NF
  • Place of Origin: Guangdong, China (Mainland)
  • cpu: Intel D525 1.8Hz Dual Core
  • RAM: DDR3 667/800MHZ 2G
  • Storage: 500G Hard disk(other storage capacity is optional,SSD optional)
  • LAN: LAN 10/100/1000 Mb/s
  • Video: Built-in GMA3150
  • Ports: 4xUSB,3XRS232,1XLAN,(2LAN optional),1XLPT(optional)
  • Resolution: 1024X768(Other Optional)
  • Touch Screen: 5-wire Resistive Touch Panel(USB)
  • LCD: 10.4"Diagonal color TFT

Packaging & Delivery

Packaging Details Carton with foam
Delivery Time 1-7 Days



Product Description



Product Picture

Specifications

SeriesTB-IPPC-AJ-104-D525B-PCI-NF
CPUIntel D525 1.8Hz Dual Core
ChipsetIntel ICH8M
VideoBuilt-in GMA3150
RAMDDR3 667/800MHZ 2G
Storage500G Hard disk(other storage capacity is optional,SSDoptional)
LAN10/100/1000M bits/
AudioBuilt-in Realtek662 HDA
Extendable Ports 1xPCI;2xfull-mini PCI express;1xparallel port,7 RS232
Ports

4xUSB 3XRS232,1XLAN,(2LAN optional),1XLPT(optional)

6RS232(optional),6USB(optional)

LCD10.4"Diagonal color TFT
Aspect ratio4:3
Resolution1024X768(Other Optional)
Dots2072(H) x (RGB) x 768(V) = 2,359,296 (dots)
Brightness280nits(LED),800nits/LED Highlight Backlight(optional)
Contrast ratio300:1(Typ.)
Viewing angle60/60/45/60(Typ.)(CR≥10)(left/right/up/down)
Touch Screen5-wire Resistive Touch Panel (USB) (Optional Other)
Speakers2 x 2W Stereo Speakers(optional) 0.3million up to 2 million (optional)
CameraNone (optional)
Power DC InDC 12V,4A
Operating Temp.-10°C- 50 °C
Storage Temp.-20 - 70 °C
Shell MaterialFront: Aluminum Back: Aluminum
ColorBlack White(optional)
IP Front: IP65;
Dimensions287.6X226X84.8mm
MountingVESA 100X100mm; Embedded Mounting (optional):316x250mm
Net Weight 3.6Kg
Guarantee12 month

More Product For You To Choose



Our Services



Our Services

All of our goods will pass QUALITY INSPECTIONS before shipment. Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment. More than 6 years experience in exporting to make your order more smooth. Less than one container loading is accepted. On time delivery, in general 3~25 days. Multimode payment:T/T,L/C. Special dimensions available according to request. We have CE, FCC, IP65 etc certificates Production period The machine will be delivered from factory during 10 working days after receive the buyer's advance payment. Quality guarantee The quality of equipment will be guaranteed for one year based on correct operation of buyer.



Packaging & Shipping

Package Information

Accessories: 100-240V AC to 12V-5A DC Power Adapter;

Main Board Driver CD;

Touch screen Driver CD;

Hooks for Embedded Mounting (Embedded PC only)

Dimensions:287.6X226X84.8mm

Packaged Dimensions:36X30X17cm

Net Weight:4.6kg Gross Weight:4.0kg
